Difference Between Transmission line and Waveguide

Comparison Between Transmission line and Wave guide :

Transmission line	Wave guide
Small cross-section transmission lines (like coaxial cables) can only transmit low power levels due to the relatively high fields concentrated at specific locations within the device	Metal waveguides can transmit high power levels. The fields of the propagating wave are spread more uniformly over a larger cross-sectional area than the small cross-section transmission line.
Large cross-section transmission lines can transmit high power levels.	Large cross-section (low frequency) waveguides are impractical due to large size and high cost.

what is Transmission line?

Answer:Transmission line:Definition:

"A conductor or conductors designed to carry electricity or an electrical signal over large distances with minimum losses and distortion".

What is Waveguide?

Answer:Waveguide:Definition:

"A waveguide is an electromagnetic feed line used in microwave communications, broadcasting, and radar installations. A waveguide consists of a rectangular or cylindrical metal tube or pipe. The electromagnetic field propagates lengthwise. Waveguides are most often used with horn antenna s and dish antenna s".
